5KG LPG cylinder main parameters
Medium: LPG
Cylinder Weight: 7.6KG ±1KG
Cylinder Material: HP295
Cylinder Volume (nominal volume): 12L
Cylinder Height: 425MM soil 10MM
Cylinder Diameter: 244MM
Cylinder Design Wall Thickness: 1.8MM
Hydrostatic Pressure: 3.2MPA
Gas Tightness Test Pressure: 2.1MPA
10KG LPG cylinder main parameters
Medium: LPG
Cylinder Weight: 12.2KG±1KG
Cylinder Material: HP295
Cylinder Volume (nominal volume): 23.5L
Cylinder Height: 640MM +10MM
Cylinder Diameter: 280MM
Cylinder Design Wall Thickness: 2.1MM
Hydrostatic Test Pressure: 3.2MPA
Gas Tightness Test Pressure: 2.1MPA
15KG LPG cylinder main parameters
Medium:LPG
Cylinder Weight: 15.5KG±1KG
Cylinder Material: HP295
Cylinder Volume (nominal volume): 35.5L
Cylinder Height: 685MM 20MM
Cylinder Diameter: 314MM
Cylinder Design Wall Thickness: 2.3MM
Hydrostatic Test Pressure: 3.2MPA
Gas Tightness Test Pressure: 2.1MP
