CNG Compressor technical parameters
Inlet Pressure Range
| 5.0MPa |
Voltage | 380V |
Piston Stroke | 2*100mm |
Operation Mode | Rated |
Number Of Cylinders | 2 |
Inlet Air Temperature | 30℃ |
Maximum outlet Pressure | 25.0MPa |
Explosion-proof Grade | dIIBT4 |
Compression Stages | 2Class |
| Minimum Speed | 985rpm |
| Cylinder Lubrication | 2*3-5g/min |
| Maximum Exhaust Temperature | ＜140℃ |
| Maximum Shaft Power | 183kW |
| Cooling Method | Mixed cold |
| Start Method | Soft start |
| Maximum Speed | 985rpm |
| Maximum Gas Outlet Temperature | Temperature +15℃ |
