Remark: If you choose a mass meter, it can measure liters, gallons, and mass (kg) at the same time.
Product Features
Automatic proportion adjustment for butane and propane.
Printer (optional)
Stops fueling by integer sale.
Screen touch
Automatic temperature compensation function
Electronic Calibration.
Fueling times limit.
Can add solar power function
Can set the decimal point for the display, so it can be used in many countries with different currency rates.
Leaves communication ports, so it can communicate with the gas station management system.
Can add GPRS function to connect with a mobile phone to check data and set unit price anytime, anywhere
Can do OEM as required
Technical Specification
Measurement Precision | ±0.5% |
Repeatability Error | ≤0.5% |
Unit Of Measurement | Gas filling capacity: liter or kg |
| Amount | Yuan |
| Unit Price | Yuan/L |
| Single Range | (1-9900.00) L or Yuan |
Cumulative Range | (1-99999999.99) L or Yuan |
Density Preset Range | 0.5000～0.6999 |
Gas-filling Preset Range | 0.3～9000L |
| Unit Price Range | 0～9999,0～999999 (variable) |
Single Range | 1～999.99,1～999999.99（variable） |
Accumulative Range | 0～9999999999.99 |
Rated Working Pressure | 2.2MPa |
Minimum Measurand | 2.5kg or 5L |
Ambient Temperature | -40℃ ~ +55℃ |
Humidity | 30%~90% |
Air Pressure | 86kPa~106kPa |
Power | AC220V(+10%,-15%)，(50±1)Hz |
Rating Power | ＜100W |
Flow Rate | 45L/Min |
Nozzle No. | 1or2（Can do OEM） |
Floumeter type | Piston or mass meter |
